Hydraulic Motor CPMS160C

Motor (Hydraulic) CPMS160C

This motor is characterised by its high quality and its reasonable price.

This product’s features are as follows:

• hydraulic motor CPMS160C
• displacement: 160 ccm/REV
• ports: G 1/2’’
• shaft: Ø 32 mm cylindrical with key A10 x 8 x 45
• 4-hole SAE flange
• disc valve type
• internal check valve
• incl. high pressure seal up to 150 bar
• usage without drain line possible
• OEM quality
• optimized for small spaces

Our CPMS160C motors are interchangeable to the following manufacturers:

CPMS160C
Danfoss OMS160 (151F0203, 151F0503)
M+S Hydraulic (MS160C)
Hydraulik Nord GMS160 (640-K201)
White WS (355160AH321AAAAA)
Eaton 2000 (104-1387, 104-3042-006)
SAM / Brevini HRS (HRS160A4M09CL320N)



Technical data:


Type	CPMS80	CPMS100	CPMS125	CPMS160	CPMS200	CPMS250	CPMS315	CPMS400	CPMS475
Displacement [ccm/REV]	80.6	100.8	125	154	194	243	311	394	475
max. Speed [RPM]	800	748	600	470	375	300	240	185	155
max. Torque [daNm]	22.5	29	36.5	48.5	58.6	70.8	88	88	91
max. Power [kW]	16	18	18	18.1	18.1	18	17	11	9
max. Pressure drop [bar]	205	205	205	210	210	200	200	160	140
max. Oil flow [l/min]	65	75	75	75	75	75
