Hydraulic Gear Pump, Group 1, europ. flange, pipe mounting, Conical shaft 1:8, Selectable displacement 1 up to 7,9 ccm/REV

Hydraulic Gear Pump, Group 1, europ. flange, pipe mounting, Conical shaft 1:8, Selectable displacement 1 up to 7,9 ccm/REV

This pump is characterised by its high quality and reasonable price.

Its features are as follows:

• group 1
• displacement 1 ccm/REV
• shaft: conical 1:8
• centering Ø 25,4mm
• inlet / outlet port: pipe mounting 3/8’’
• Plessey flange
• rotation direction: right

Technical data:


Displacement	Dimensions				Technical data
	A	B	Inlet ports	Outlet ports	Max.pressure	Speed
cm3	mm	mm	G (mm)	G (mm)	bar	tr/min
1	39.5	82.3	G3/8"	G3/8"	250	700...3500
1.25	39.9	83	G3/8"	G3/8"	250	700...3500
1.8	40.7	84.7	G3/8"	G3/8"	250	700...3500
2	41.1	85.5	G3/8"	G3/8"	250	700...3500
2.5	42.1	87.5	G3/8"	G3/8"	250	700...3500
3.15	43.4	90.4	G3/8"	G3/8"	250	700...3500
3.65	44.4	92.4	G3/8"	G3/8"	250	700...3500
4.2	45.5	94.5	G3/8"	G3/8"	250	700...3000
5.1	47.1	97.5	G3/8"	G3/8"	250	700...3000
5.7	48.5	100.5	G3/8"	G3/8"	200	700...2500
6.1	49.4	102.2	G3/8"	G3/8"	200	700...2500
7	51.2	106	G3/8"	G3/8"	180	700...2000
7.9	52.6	109	G3/8"	G3/8"	170	700...2000

Pump dimensions:



Download catalogue:




Hydraulic component for integration in hydraulic systems

All our hydraulic products are new, unused and in OEM quality (except when explicitly declared otherwise). Should a particular item not be in stock or not be represented here, please don’t hesitate to contact us. We will immediately try to find an appropriate solution pertaining to your given specifications. Moreover, we are constantly expanding our product range to offer you a wide variety of hydraulic components at reasonable prices. Hydromot hydraulics – always an excellent choice at low prices!
